SS 304 ERW Pipes are manufactured by forming stainless steel strip into a tubular shape and joining the longitudinal seam using electric resistance welding. Made from UNS S30400, they offer good general corrosion resistance, formability and weldability for compatible industrial applications.
Metalloy Steel supplies SS 304 ERW Pipes in India for fabrication and piping requirements. Share your required outside diameter, wall thickness, length, quantity and applicable standard to confirm specifications and request a quotation.
Comprehensive standard parameters and dimensions for SS 304 ERW stainless steel welded pipe products.
| Parameter | Details |
|---|---|
| Product Name | SS 304 ERW Pipes / SS 304 Welded Pipes |
| Stainless Steel Grade | SS 304 |
| UNS Designation | S30400 |
| Material Type | Austenitic stainless steel |
| Manufacturing Process | Electric Resistance Welding (ERW) |
| Other Welded Pipe Process | Electric Fusion Welding (EFW) |
| Applicable Standards | ASTM A312, ASTM A778 or other applicable specifications, depending on pipe type and service |
| Dimensions | Outside diameter and wall thickness as per order requirements (NB Sizes & Schedules) |
| Length | Standard or cut lengths, subject to specification and availability |
| Surface Finish | As manufactured or specified finish |
| Supply Requirements | Grade, dimensions, quantity, intended service and inspection requirements |
| Chemical Composition & Mechanical Properties | Tested and certified to relevant ASTM / ASME specifications |
International standard designations corresponding to UNS S30400.
| Standard / System | Equivalent Designation |
|---|---|
| UNS Designation | S30400 |
| Werkstoff / W.Nr. | 1.4301 |
| AFNOR (France) | Z7CN18-09 |
| EN (European Standard) | X5CrNi18-10 |
| JIS (Japan) | SUS 304 |
| BS (British Standard) | 304S31 |
| GOST (Russia) | 08Х18Н10 |
| Chemical Element | Composition (%) |
|---|---|
| Carbon (C) | 0.08 max |
| Manganese (Mn) | 2.00 max |
| Silicon (Si) | 1.00 max |
| Phosphorus (P) | 0.045 max |
| Sulphur (S) | 0.030 max |
| Chromium (Cr) | 18.00–20.00 |
| Nickel (Ni) | 8.00–10.50 |
| Iron (Fe) | Balance |
| Mechanical Property | Value |
|---|---|
| Tensile Strength | 515 MPa min. |
| Yield Strength (0.2% Offset) | 205 MPa min. |
| Elongation | 35% min. |
| Solution Annealing Temperature | Approximately 1040°C |
For other available stainless steel pipe grades and schedules, explore our Pipes & Tubes range.
Understanding the key distinctions between resistance-welded and fusion-welded stainless steel pipes.
| Comparison | SS 304 ERW Pipes | SS 304 EFW Pipes |
|---|---|---|
| Welding Process | Electric resistance welding | Electric fusion welding |
| Typical Manufacturing Route | Formed strip or coil with a longitudinal resistance-welded seam | Formed plate or sheet joined using a fusion-welding process |
| Product Selection | Depends on the specified dimensions, standard and service requirements | Depends on the specified dimensions, standard and service requirements |
| Key Buying Consideration | Confirm the applicable ERW manufacturing and inspection requirements | Confirm the applicable EFW process, weld examination and inspection requirements |
Estimate real-time linear mass and total order weight for SS 304 ERW and stainless steel welded pipes with our live 3D visualizer engine.
Density: 7.93 g/cm3 (7930 kg/m3) | Real-time weight estimator for stainless steel pipes.
Pick a size to auto-fill OD and wall thickness, or choose Custom and enter your own.
Total Weight
32.96 kg
0.033 tonnes · 1 pc × 6.00 M
Weight per metre
5.493 kg/m
Weight per piece
32.96 kg
Inner diameter
52.48 mm
Total length
6.00 M
Spec: Metalloy Steel | Grade: SS 304 ERW Pipe | Size: 50 NB (2") SCH 40S | OD: 60.3 mm | WT: 3.91 mm | L: 6 M | Qty: 1 pc | Total: 32.96 kg
Engineered for cleanability, structural reliability, and cost-effective fluid conveyance across industrial sectors.
Used in selected milk, beverage and food-processing systems where cleanable pipe surfaces and resistance to routine process exposure are important.
Suitable for compatible water distribution lines, filtration equipment and plant connections, helping reduce reliance on coated steel pipes.
The welded pipe format supports fabrication of equipment frames, manifolds and pipe assemblies to specified dimensions.
SS 304 can be fabricated into connected pipework using qualified welding procedures, with weld quality and surface condition selected for the service.
Suitable for certain non-chloride chemical lines when material compatibility is confirmed before installation.
SS 304 can be a suitable option for general industrial service, while chloride-rich, coastal or more aggressive chemical environments may require SS 316 for better pitting resistance.
Typical components and industrial sectors relying on SS 304 ERW stainless steel pipes.
| Industry | Applications & Benefits |
|---|---|
| Food & Beverage | Milk transfer lines, beverage pipelines and bottling equipment requiring cleanable surfaces. |
| Water Treatment | Filtration systems, freshwater lines and plant connections. |
| Chemical Processing | Transfer lines for compatible chemicals and process fluids. |
| Pharmaceutical | Utility piping and process systems meeting specified hygiene and cleaning requirements. |
| Construction & Architecture | Handrails, fabricated assemblies and architectural components. |
| Industrial Engineering | Equipment connections, manifolds and fabricated piping systems. |
Metalloy Steel can discuss inspection and documentation requirements for SS 304 ERW Pipes according to the purchase specification and order scope.
Can be requested, subject to availability, to document heat-specific chemical and mechanical results.
Can help verify alloy composition and distinguish SS 304 from other stainless steel grades.
Verifies the material chemistry against the specified grade and standard.
Tests such as tensile testing can be specified according to the applicable requirements.
Checks outside diameter, wall thickness and length against the purchase order.
Visual examination and other specified weld examinations can be arranged according to the applicable standard and order requirements.
Can be discussed subject to project requirements and availability with agencies like SGS, BV, or TÜV.
Clear technical answers to frequent queries regarding SS 304 ERW pipe supply and specifications.
SS 304 ERW Pipes are stainless steel pipes made by forming steel strip into a tube and joining the longitudinal seam using electric resistance welding. They are commonly selected for fabrication and industrial applications requiring the properties of grade 304.
The UNS designation is S30400. The grade is also commonly identified as 1.4301, X5CrNi18-10 and SUS 304 under other designation systems.
They are suitable for some chemical services, but compatibility depends on the chemical composition, concentration, temperature and exposure conditions. SS 304 should not be assumed suitable for every corrosive environment.
The relevant standard depends on the intended service and product type. ASTM A312 and ASTM A778 cover different categories of austenitic stainless steel pipe and tubular products. Buyers should confirm the exact standard required for their application.
Share the required outside diameter, wall thickness, length, quantity, manufacturing standard and application with Metalloy Steel. Inspection and documentation requirements can also be included in the enquiry.
Contact Metalloy Steel, an SS 304 ERW Pipes Supplier in India, with your required pipe dimensions, wall thickness, quantity and applicable standard to discuss availability, inspection requirements and pricing.
